T-NUT
SRNO Part No. KITAGAWA (K) GMT (G) AIRTECH (A) Slot(C) PCD (F) TAP Slot(C) PCD (F) TAP Slot(C) PCD (F) TAP 122 FMS-110/135-T 10 14 8 10 14 8 10 14 8 124 FMS -150/165-T 12 20 10 12 19 10 12 20 10 115 FMS -200/210-T 14 25 12 17 19 12 14 25 … T-NUT
HARD JAWS
HARD JAWS
PIE JAWS
PIE JAWS
L TYPE SOFT JAWS
SRNO Part No. Width (B) Height (C) Length (A) KITAGAWA (K) GMT (G) AIRTECH (A) (mm) (mm) (mm) Slot(D) PCD (G) Serration (K) Slot(D) PCD (G) Serration (K) Slot(D) PCD (G) Serration (K) 122 FMS-110/135-L75 25 75 65 10 14 1.5 x 60’ 10 14 1/16X90 10 14 1/16X90 123 FMS-110/135-L100 25 100 65 10 … L TYPE SOFT JAWS
DOUBLE ANGLE SOFT JAWS
DOUBLE ANGLE SOFT JAWS
EXTRA HEIGHT SOFT JAWS
SRNO Part No. Width (C) Height (A) Length (B) KITAGAWA (K) GMT (G) AIRTECH (A) WEIGHT (KG) (mm) (mm) (mm) Slot (F) PCD (E) Serration (D) Slot (F) PCD (E) Serration (D) Slot (F) PCD (E) Serration (D) 111 FMS-110/135-32 25 32 65 10 14 1.5 x 60’ 10 14 1/16X90 10 14 1/16X90 … EXTRA HEIGHT SOFT JAWS
STANDARD SOFT JAWS
KITAGAWA Sr no. Size/Part no. Width (C) Height((D) Length (B) Slot (G) PCD (E) Serration (J) Weight(kg) 1 FMS-K-110/135/4″ 25 25 65 10 14 1.5 x 60◦ 1 2 FMS-K-150/165/6″ 32 32 80 12 20 1.5 x 60◦ 2 3 FMS-K-200/210/8″ 38 38 100 14 25 1.5 x 60◦ 3.4 4 FMS-K-250/10″ 50 50 110 … STANDARD SOFT JAWS
EXTRA LONG SOFT JAWS
KITAGAWA SRNO Partno. CHUCK SIZE S1 (LENGHT) S2 (WIDTH) S3 (HEIHT) Slot (S4) PCD (S5) Serration (S6) WEIGHT (KG) 18 FMS-K-165-100 165 100 32 32 12 20 1.5 x 60’ 2.4 19 FMS-K-165-120 165 120 38/40 50 12 20 1.5 x 60’ 5.6 20 FMS-K-165-150 165 150 38/40 75 12 20 1.5 x 60’ 10.5 … EXTRA LONG SOFT JAWS
EXTRA WIDTH SOFT JAWS
KITAGAWA SRNO Partno. CHUCK SIZE S1 (LENGHT) S2 (WIDTH) S3 (HEIHT) Slot (S4) PCD (S5) Serration (S6) WEIGHT (KG) 18 FMS-K-165-100 165 100 32 32 12 20 1.5 x 60’ 2.4 19 FMS-K-165-120 165 120 38/40 50 12 20 1.5 x 60’ 5.6 20 FMS-K-165-150 165 150 38/40 75 12 20 1.5 x 60’ 10.5 … EXTRA WIDTH SOFT JAWS
